Duo-Tone Wall Battery
A matte-white front with a black frame, a compact LCD and four tactile silver buttons — wall-mounted or floor-placed, with two U-handles for easy handling. 5 to 16 kWh of quiet LiFePO4 storage for apartments, garages and shops.
Overview
The DUO-TONE series brings a bolder look to wall-mounted storage — a matte-white front panel framed in black, with a compact LCD in the lower right and four silver buttons for direct control. Two U-handles on the side make it easy to lift, carry and service, and the design works both on the wall and as a floor unit. It delivers the same dependable 51.2 V LiFePO4 performance as the rest of the RUIDASIMAI wall-mounted family.
Technical Specifications
| Parameter | Value |
| Nominal Energy | 5 kWh / 10 kWh / 16 kWh (customizable) |
| Product Type | Wall-Mounted Lithium Battery |
| Cell Chemistry | LiFePO4 |
| Module Configuration | 16S1P |
| Nominal Capacity | 100 Ah / 200 Ah / 314 Ah |
| Nominal Voltage | 51.2 Vdc |
| Operating Voltage Range | 44.8 – 57.6 Vdc |
| Max. Continuous Charge Current | 50 A (5 kWh) / 100 A (10 kWh) / 150 A (16 kWh) |
| Max. Continuous Discharge Current | 100 A (5 kWh) / 200 A (10 kWh) / 300 A (16 kWh) |
| Cycle Life | ≥ 6,000 (5 kWh) / ≥ 8,000 (10 & 16 kWh) @ 25°C |
| Communication Interface | CAN / RS485 / RS232 |
| Display Panel | LCD (round display with status ring) |
| Ingress Protection | IP54 (optional) |
| Cooling Type | Natural air cooling |
| Parallel Expansion | Up to 64 units |
| Certifications | UL9540 & UL1973 |
| Warranty | > 5 years |
